Begin with attention

What will this token copy?

Follow one query: match keys, mix values, then change an input and explain an unfamiliar result.

Start the attention lesson

This tab carries your example once; new tabs and reloads start separately.

Change the query · one unmasked row

Shared normalization: m = 1.414; Z = 1.736.

  1. Source Aindex 0
    Dot
    0
    Scaled
    0
    Share
    0.14
    Carry w_Av_A
    [0.28, 0]
  2. Source Bindex 1
    Dot
    2
    Scaled
    1.414
    Share
    0.576
    Carry w_Bv_B
    [0, 1.152]
  3. Source Cindex 2
    Dot
    1
    Scaled
    0.707
    Share
    0.284
    Carry w_Cv_C
    [-0.284, -0.284]

Output o = [-0.004, 0.868]

Compared with q = [2, 1]:

Scores same; shares same; output same.

Worked example, not a test or model run. Given vectors, not learned meanings. Match the query with keys; mix values, not keys. All three sources are allowed in this view.

1 · Match and scaleq · kᵢ → sᵢ = (q · kᵢ) / √2sum(qj * kj for qj, kj in zip(q, k)) / sqrt(2)
2 · Share one denominatorwᵢ = exp(sᵢ − m) / Zexps = [exp(s - max(scores)) for s in scores]weights = [e / sum(exps) for e in exps]
3 · Carry the valuescᵢ = wᵢvᵢ; o = Σᵢ cᵢsum(w * v[j] for w, v in zip(weights, values))

m is the shared maximum scaled score; Z = exp(s_A − m) + exp(s_B − m) + exp(s_C − m). Subtracting the same maximum avoids large exponentials without changing the shares. Each carry is a weighted source value; sum the three contributions coordinate by coordinate for output o.

The reference uses the same current keys and values, with q = [2, 1]. Not every query edit changes the mixture. Solid amber borders mark numerical changes; dashed teal borders mark values unchanged within 1e-12. Labels round to three decimals, not the calculation.

Source A · index 0
k_A = [-1, 2]; v_A = [2, 0]
Source B · index 1
k_B = [1, 0]; v_B = [0, 2]
Source C · index 2
k_C = [0, 1]; v_C = [-1, -1]
Inspect precise numbers and input coordinates

Finite JavaScript numbers before display rounding; −0 is retained where supplied. Tiny allowed shares can underflow to zero; that is not a mask.

q = [2, 1]
A: key=[-1, 2]; value=[2, 0]; dot=0; score=0; share=0.14002924504337802; contribution=[0.28005849008675604, 0]
B: key=[1, 0]; value=[0, 2]; dot=2; score=1.414213562373095; share=0.575975345215362; contribution=[0, 1.151950690430724]
C: key=[0, 1]; value=[-1, -1]; dot=1; score=0.7071067811865475; share=0.28399540974126003; contribution=[-0.28399540974126003, -0.28399540974126003]
m=1.414213562373095; stable denominator=1.736185425829454
output=[-0.00393691965450399, 0.8679552806894639]
Read the full Python witness

This runnable Python witness uses the current controls and the same labels. No NumPy or random inputs are needed.

from math import exp, sqrt

labels = ["A","B","C"]
q = [2,1]
keys = [[-1,2],[1,0],[0,1]]
values = [[2,0],[0,2],[-1,-1]]

d_k = len(q)  # key dimension, NOT number of sources or value width
raw_scores = [sum(qj * kj for qj, kj in zip(q, k)) for k in keys]
scores = [s / sqrt(d_k) for s in raw_scores]
exps = [exp(s - max(scores)) for s in scores]
weights = [e / sum(exps) for e in exps]
output = [sum(w * v[j] for w, v in zip(weights, values))
          for j in range(len(values[0]))]

for label, raw, score, weight in zip(labels, raw_scores, scores, weights):
    print(label, round(raw, 3), round(score, 3), round(weight, 3))
print("output", [round(x, 3) for x in output])

Expected output: [-0.004, 0.868] (rounded to three decimals).

Inspect key and value geometry
Key space: query and source keysQuery q is [2, 1]. Source coordinates and calculations are available in the labelled numeric readouts.xy0k_Ak_Bk_Cq
Key space only. Each grid interval is 1 coordinate unit on both axes. Amber marks the query q you control; ink marks the three fixed keys.
Value space: weighted output and source valuesOutput o is [-0.004, 0.868]. Source coordinates and calculations are available in the labelled numeric readouts.xy0v_Av_Bv_Co
Value space only. Each grid interval is 1 coordinate unit on both axes. Teal marks the mixed output o; the triangle bounds its possible positions.
