Direct Preference Optimization

DPO turns pairwise preferences into binary cross-entropy on reference-relative log odds, using the KL-regularized RLHF optimum to make the policy itself an implicit reward model.

Advanced · Undergraduate mathematics · about 18 minutes

Reading map and next steps

Intuition

The idea in plain words, before the symbols.

Suppose a prompt xx has two candidate completions:

  • ywy_w: the preferred completion
  • yℓy_\ell: the rejected completion

RLHF usually trains a reward model rϕ(x,y)r_\phi(x,y), then runs an RL algorithm to make the policy choose higher-reward outputs while staying close to a reference model.

DPO asks a sharper question: can the policy itself act as the reward model?

Under the KL-regularized RLHF objective, the answer is yes, but only up to a prompt-only constant. If a policy has moved away from the reference model, that movement gives a convenient representative of an implicit reward class:

r^θ(x,y)=βlog⁡πθ(y∣x)πref(y∣x).\hat r_\theta(x,y) = \beta\log \frac{\pi_\theta(y\mid x)} {\pi_{\mathrm{ref}}(y\mid x)}.

The exact reward can differ from this representative by a term that depends only on xx. Only reward differences matter for preference pairs, so that prompt-only term cancels, and DPO compares how much the current policy has changed the winner-vs-loser odds relative to the reference policy.

The core idea is:

A preferred response should beat a rejected response by more than the reference model already made it beat it.

That "more than the reference" phrase is the whole mechanism. DPO is not just "make the winner more likely." It is binary cross-entropy on reference-relative log odds.

A finite set of recorded comparisons constrains only the pairs it compares. Records that compare A with B say how the policy should move A relative to B; they say nothing about a response they never mention, or about how that response should be judged. The preference-coverage investigation follows four such records through one update, then separates what they fit from what they leave undecided.

Sources. DPO was introduced by Rafailov et al. (2023), "Direct Preference Optimization: Your Language Model is Secretly a Reward Model". Azar et al. (2024), "A General Theoretical Paradigm to Understand Learning from Human Preferences", analyze when its regularization fails, and Xu et al. (2024), "Is DPO Superior to PPO for LLM Alignment?", compare it with PPO-based RLHF.

Study prompts for this section: Intuition
Study prompts

Each button copies a prompt about this section to your clipboard, for an AI assistant you already use. Nothing is sent by this site.

Mathematics

Definitions, assumptions and the derivation.

DPO's implicit reward is the β\beta-scaled policy/reference log-ratio:

r^θ(x,y)=βlog⁡πθ(y∣x)πref(y∣x).\hat r_\theta(x,y) = \beta\log\frac{\pi_\theta(y\mid x)}{\pi_{\mathrm{ref}}(y\mid x)}.

Setup and shapes

For a prompt xx, πθ(y∣x)\pi_\theta(y\mid x) is the full sequence probability of completion yy. In an autoregressive language model,

log⁡πθ(y∣x)=∑tlog⁡πθ(yt∣x,y<t).\log \pi_\theta(y\mid x) = \sum_t \log \pi_\theta(y_t\mid x,y_{<t}).

A preference datum is (x,yw,yℓ)(x,y_w,y_\ell). All compared completions must have positive probability under the reference policy for the log ratio to be finite.

Define the policy and reference log-odds:

aθ=log⁡πθ(yw∣x)−log⁡πθ(yℓ∣x),a_\theta = \log\pi_\theta(y_w\mid x) - \log\pi_\theta(y_\ell\mid x),

and

aref=log⁡πref(yw∣x)−log⁡πref(yℓ∣x).a_{\mathrm{ref}} = \log\pi_{\mathrm{ref}}(y_w\mid x) - \log\pi_{\mathrm{ref}}(y_\ell\mid x).

The reference-relative margin is

mθ=aθ−aref.m_\theta=a_\theta-a_{\mathrm{ref}}.

DPO predicts the preference probability as

Pθ(yw≻yℓ∣x)=σ(βmθ).P_\theta(y_w\succ y_\ell\mid x) = \sigma(\beta m_\theta).

For one hard winner/loser label, the DPO loss is

LDPO=−log⁡σ(βmθ).\mathcal L_{\mathrm{DPO}} = -\log\sigma(\beta m_\theta).

Let sθ=σ(βmθ)s_\theta=\sigma(\beta m_\theta). The browser demo below uses a soft target p∗p^* so the finite target log-odds is visible:

Lsoft=−p∗log⁡sθ−(1−p∗)log⁡(1−sθ).\mathcal L_{\mathrm{soft}} = -p^*\log s_\theta -(1-p^*)\log(1-s_\theta).

Ordinary hard-label DPO is the edge case p∗→1p^*\to 1, where an isolated two-response target diverges.

From KL-regularized RLHF to DPO

For a fixed prompt xx, write Kx(π)K_x(\pi) for the distribution-level KL from a candidate policy to the reference policy at that prompt. The direction is π(⋅∣x)\pi(\cdot\mid x) to πref(⋅∣x)\pi_{\mathrm{ref}}(\cdot\mid x):

Kx(π)=KLx(π∥πref).K_x(\pi) = \mathrm{KL}_x(\pi\|\pi_{\mathrm{ref}}).

Also write the expected reward as

Rx(π)=Ey∼π(⋅∣x)[r(x,y)].R_x(\pi) = \mathbb E_{y\sim\pi(\cdot\mid x)}[r(x,y)].

The KL-regularized RLHF objective is to maximize

Jx(π)=Rx(π)−βKx(π).J_x(\pi) = R_x(\pi)-\beta K_x(\pi).

Its optimizer has the reweighted form

πr(y∣x)=πref(y∣x)exp⁡(r(x,y)/β)Z(x).\pi_r(y\mid x) = \frac{\pi_{\mathrm{ref}}(y\mid x)\exp(r(x,y)/\beta)} {Z(x)}.

Rearrange it:

r(x,y)=βlog⁡πr(y∣x)πref(y∣x)+βlog⁡Z(x).r(x,y) = \beta\log \frac{\pi_r(y\mid x)} {\pi_{\mathrm{ref}}(y\mid x)} + \beta\log Z(x).

The partition term Z(x)Z(x) depends on the prompt, not on which completion won. Bradley-Terry preferences use reward differences, so the prompt-only term cancels between ywy_w and yℓy_\ell.

Bradley-Terry likelihood

The Bradley-Terry model (Bradley and Terry, 1952) writes a preference as

P(yw≻yℓ∣x)=σ(r(x,yw)−r(x,yℓ)).P(y_w\succ y_\ell\mid x) = \sigma(r(x,y_w)-r(x,y_\ell)).

Substituting the implicit reward gives the DPO probability. With the margin mθ=aθ−arefm_\theta=a_\theta-a_{\mathrm{ref}} from above:

Pθ(yw≻yℓ∣x)=σ(βmθ).P_\theta(y_w\succ y_\ell\mid x) =\sigma(\beta m_\theta).

Maximum likelihood on preference labels gives the DPO loss. This is why DPO is a supervised objective even though it comes from a KL-regularized RLHF derivation.

What beta does

Here β\beta follows the DPO paper's convention: it is the coefficient on the KL penalty in the KL-regularized RLHF objective.

  • Larger β\beta means a stronger reference anchor in the underlying RLHF objective.
  • Smaller β\beta means a given preference probability requires a larger policy/reference log-ratio gap.
  • In the DPO loss, β\beta also scales the sigmoid margin, so it affects optimization dynamics. Do not read "larger β\beta" as simply "trust preferences more."

For a soft preference probability p∗p^*, matching p∗p^* requires

m∗=logit⁡(p∗)β.m^*=\frac{\operatorname{logit}(p^*)}{\beta}.

Limits of the mechanism

DPO removes the explicit reward-model training stage and the RL loop. It does not remove the assumptions behind preference learning.

It still relies on a pairwise preference model such as Bradley-Terry. It only identifies rewards up to prompt-dependent constants. It needs a usable reference policy. And in an isolated two-response hard-label setting, the logistic loss can keep increasing the winner-over-loser log-ratio rather than settling at a finite target.

Azar et al. (2024) make the last point precise: if a preference is deterministic, the DPO optimum gives the loser probability zero whatever the value of β\beta, so the KL term no longer holds the policy near the reference. With only a few comparisons per pair, the estimated preference can easily be 1 even when the true preference is, say, 0.8. Their IPO objective replaces the log-sigmoid with a squared loss whose target margin stays finite.

Removing the RL loop also does not settle which method works better. Xu et al. (2024) argue that DPO can favor responses that never appear in the preference data, and report that a carefully tuned PPO pipeline outperformed DPO on the dialogue and code-generation benchmarks they studied.

Several records for one prompt

A finite set of records k=1,…,Nk=1,\dots,N for the same prompt gives each record an oriented pair (wk,ℓk)(w_k,\ell_k) with its own scaled margin vk=βmkv_k=\beta m_k. The empirical objective used in the investigation below is the mean

Lˉ=1N∑k=1N−log⁡σ(vk).\bar{\mathcal L} = \frac1N\sum_{k=1}^{N}-\log\sigma(v_k).

Taking the mean is a choice made here; the paper's reference code returns one loss per pair. For a free categorical policy π=softmax⁡(z)\pi=\operatorname{softmax}(z) over the candidate completions, ∇z(log⁡πw−log⁡πℓ)=ew−eℓ\nabla_z(\log\pi_{w}-\log\pi_{\ell})=e_{w}-e_{\ell}, so each record contributes

∇z(−log⁡σ(vk))=−β σ(−vk) (ewk−eℓk).\nabla_z\bigl(-\log\sigma(v_k)\bigr) = -\beta\,\sigma(-v_k)\,(e_{w_k}-e_{\ell_k}).

The weight is σ(−vk)\sigma(-v_k): a record the policy already orders well pulls weakly, and a badly ordered one pulls with weight near 1. The records constrain only the log-ratios of pairs they compare, so a completion that appears in no record is left free by Lˉ\bar{\mathcal L}. This is a small finite version of the concern Xu et al. raise about responses outside the preference data. The preference-coverage investigation works it through for three completions and four records, and notes where Appendix A.4 of the arXiv version used here (v3) prints a different orientation.

Study prompts for this section: Mathematics
Study prompts

Each button copies a prompt about this section to your clipboard, for an AI assistant you already use. Nothing is sent by this site.

Code

The same calculation as runnable code, in the notation of the derivation.

This finite-action example checks the derivation in a setting where it holds exactly. A synthetic reward defines the KL-regularized target policy. DPO sees full-support, exact soft Bradley-Terry preference probabilities and recovers the same unconstrained categorical policy through reference-relative log-ratio cross-entropy. Sampled hard labels, missing pairs, or a restricted neural parameterization would not make the equality exact in finite data.

import numpy as np

def softmax(z):
    z = z - z.max()
    e = np.exp(z)
    return e / e.sum()

def sigmoid(x):
    return 1.0 / (1.0 + np.exp(-x))

def kl(p, q):
    return float(np.sum(p * (np.log(p) - np.log(q))))

# One prompt, three possible completions.
# Shapes: ref, reward, logits, pi are all (K,).
ref = np.array([0.15, 0.70, 0.15], dtype=float)
reward = np.array([1.0, 0.2, -0.5], dtype=float)
beta = 0.5
log_ref = np.log(ref)

# KL-regularized RLHF optimum:
# pi*(y|x) is proportional to pi_ref(y|x) exp(r(x,y)/beta).
pi_star = ref * np.exp(reward / beta)
pi_star = pi_star / pi_star.sum()

# DPO sees pairwise preferences. We use exact Bradley-Terry
# probabilities instead of sampled hard labels so the equality is visible.
pairs = [(0, 1), (0, 2), (1, 2)]

# Initialize policy at the reference.
logits = log_ref.copy()
lr = 0.2

for _ in range(3000):
    grad = np.zeros_like(logits)

    for i, j in pairs:
        rel_log_odds = (logits[i] - logits[j]) - (log_ref[i] - log_ref[j])
        pred = sigmoid(beta * rel_log_odds)

        target = sigmoid(reward[i] - reward[j])

        # Binary cross-entropy gradient for the soft preference target.
        g = beta * (pred - target)
        grad[i] += g
        grad[j] -= g

    logits -= lr * grad / len(pairs)
    logits -= logits.mean()  # logits are identifiable only up to a constant

pi = softmax(logits)

print("reference policy:      ", np.round(ref, 3))
print("KL-reg optimum:        ", np.round(pi_star, 3))
print("DPO learned policy:    ", np.round(pi, 3))
print("KL(pi || ref):         ", round(kl(pi, ref), 4))

assert np.allclose(pi, pi_star, atol=1e-6)

for i, j in pairs:
    implicit_gap = beta * (
        (np.log(pi[i]) - np.log(ref[i]))
        - (np.log(pi[j]) - np.log(ref[j]))
    )
    reward_gap = reward[i] - reward[j]
    assert abs(implicit_gap - reward_gap) < 1e-6

for i, j in pairs:
    dpo_pref = sigmoid(beta * (
        (np.log(pi[i]) - np.log(ref[i]))
        - (np.log(pi[j]) - np.log(ref[j]))
    ))
    bt_pref = sigmoid(reward[i] - reward[j])
    assert abs(dpo_pref - bt_pref) < 1e-6

The preference-coverage investigation below the demo has its own code for a different example: four hard-label records over three completions, row losses computed stably from logit differences, the averaged gradient and one step, supplied policies that fit the records equally well, and a NumPy transcription of the paper's Appendix B dpo_loss, which refuses inputs outside its supported domain. The site's tests run that code; the code above is unchanged.

Study prompts for this section: Code
Study prompts

Each button copies a prompt about this section to your clipboard, for an AI assistant you already use. Nothing is sent by this site.

Demo

Change an input, predict the result, and see which quantities respond.

ExploreChange one control at a time and name what responds.An optional observation guide follows the demo.

Explore Direct Preference Optimization

Loading the interactive demo…

Observation guide

Optional and ungraded. Opening a guide saves nothing.

Choose what to inspect in Direct Preference Optimization, then open its guide.

The demo collapses the world to two completions, ywy_w and yℓy_\ell, so its KL is the binary KL over this toy pair, not the full language-model KL over all completions. Change the reference winner probability, the soft target preference, and β\beta. Watch how the required policy log-odds moves relative to the reference, how the DPO probability changes, and when the two-action KL from the reference spikes.

The demo works as soon as the page loads. A short question after it is optional practice and changes nothing in the demo.

After this section, the preference-coverage investigation is a different example: three complete responses, four recorded hard-label comparisons and one full-batch update with fixed β\beta and step size, followed by policies that fit those records equally well and evaluation rubrics written separately.

Study prompts for this section: Demo
Study prompts

Each button copies a prompt about this section to your clipboard, for an AI assistant you already use. Nothing is sent by this site.

Investigation · three responses, four recorded comparisons

What did the recorded preferences identify?

Four example records about one prompt cause one calculable update. Policies that fit those records equally well can still treat response C very differently, and nothing in the records says how C should be judged. The parts below keep three things apart: the fit to the records, the step one optimizer actually takes, and an evaluation written separately.

Illustrative numbers in a finite teaching calculation, not a training run, a dataset or a measurement of human values. Fixed here: β = ½, step size η = 1, reference q = (⅓, ⅓, ⅓), start z₀ = (0, 0, 0). The ratio demo above keeps its own two-response example and controls; nothing here changes it or is saved.

Policy
π = softmax(z) over the complete responses A, B and C, with three free logits z.
Record
“w ≻ ℓ”: one hard label with an ID, meaning w was preferred to ℓ.
Margin
m: how far the policy’s log-odds of w over ℓ have moved beyond the reference’s; v = βm.
Recorded fit
The mean over records of −log σ(v), the DPO loss for hard labels.

The records and what they compare

Four records for one prompt, written for this example. Choose one to trace through the step.

Record IDs, not people: 3 of these 4 records prefer A to B. That is a proportion of four example labels, not a count of independent judges or a population share.

Comparison coverage of the four recordsA to B: 3 records prefer A (r1, r2, r3) and 1 prefers B (r4). C is compared with nothing. Selected: r4, B preferred to A.A ≻ B: r1, r2, r3B ≻ A: r4ABCC: no recorded comparison
An arrow points from the preferred response to the other one and lists the records behind it. Its drawing does not encode confidence or quality. The highlighted arrow belongs to the traced record, r4.

In words: the A–B pair has 3 records one way and 1 the other. No record compares A with C or B with C, so C is uncompared. An absent comparison is not a judgment that C is bad, and it is not a held-out prompt.

One full-batch step

m = (zw − zℓ) − log(qw / qℓ)v = βmrow loss −log σ(v)row gradient −β σ(−v)(ew − eℓ)L = mean of the rowsz₁ = z₀ − η∇L

Softmax normalization cancels inside zw − zℓ, which equals log πw − log πℓ. The reference term is written even though it is log 1 = 0 here. All four rows are evaluated at the same z₀, averaged, and then one update is made.

Each record at z₀ = (0, 0, 0), the mean, and each record again after the step
RecordPreferredm at z₀σ(v) at z₀Loss at z₀Gradient at z₀ (A, B, C)Loss at z₁
r1A ≻ B00.50.693147(−0.25, 0.25, 0)0.632599
r2A ≻ B00.50.693147(−0.25, 0.25, 0)0.632599
r3A ≻ B00.50.693147(−0.25, 0.25, 0)0.632599
r4B ≻ A00.50.693147(0.25, −0.25, 0)0.757599
Mean of 40.693147(−0.125, 0.125, 0)0.663849

r4 prefers B to A. At z₀ its margin is m = (zB − zA) − log(qB / qA) = (0 − 0) − log 1 = 0, so v = 0, σ(v) = 0.5 and its loss is −log σ(v) = 0.693147. Its gradient −β σ(−v)(eB − eA) = (0.25, −0.25, 0). Subtracting it would, for this record alone, raise zB and lower zA. After the averaged step its loss is 0.757599, higher than before.

z₁ = (0, 0, 0) − 1 · (−0.125, 0.125, 0) = (0.125, −0.125, 0)

Reference q, which is also π(z₀)start
  • A0.333333
  • B0.333333
  • C0.333333

Sum 1. One scale from 0 to 1 for all three responses; the tick marks the reference q = ⅓. π(z₀) equals q only because z₀ is a constant shift of log q.

π(z₁) after the stepafter one step
  • A0.375757
  • B0.292639 below q
  • C0.331604 below q

Sum 1. One scale from 0 to 1 for all three responses; the tick marks the reference q = ⅓.

C’s logit did not move: its gradient entry is 0. Its probability still fell, from 0.333333 to 0.331604, because πC = ezC / (ezA + ezB + ezC) and the denominator grew from 3 to 3.015645. With shared neural parameters C’s logit need not stay fixed; the free logits here are a deliberate simplification.

The mean loss fell from 0.693147 to 0.663849, while r4’s own loss rose to 0.757599. A lower mean does not mean every record is better fitted.

This is one step of one optimizer from one start, with β and η fixed. It is not a training run, and its result is not one of the policies in part 3.

A different question: which complete policies fit these records best?

Over all strictly positive policies, the smallest mean record loss is 0.562335, reached when the model’s predicted probability that A is preferred to B equals the records’ 3/4. At β = ½ and this reference that fixes one ratio, πA / πB = 9. Nothing in the records fixes πC. The two policies below are supplied for comparison; neither was produced by the step in part 2.

Supplied policy Psupplied, not trained
  • A0.810000
  • B0.090000 below q
  • C0.100000 below q

Sum 1. One scale from 0 to 1 for all three responses; the tick marks the reference q = ⅓.

Mean record loss
0.562335
πA / πB
9
Predicted A over B, σ(βm)
0.75
Sampling A given A or B
0.9
Sampling A
0.81
Supplied policy Qsupplied, not trained
  • A0.270000 below q
  • B0.030000 below q
  • C0.700000

Sum 1. One scale from 0 to 1 for all three responses; the tick marks the reference q = ⅓.

Mean record loss
0.562335
πA / πB
9
Predicted A over B, σ(βm)
0.75
Sampling A given A or B
0.9
Sampling A
0.27
Four numbers that are easy to conflate
QuantityValueWhat it is
Records preferring A to B3/4A proportion of these four example labels
σ(βm) for A over B0.75 at P and Q; 0.531209 after the stepThe model’s predicted preference, which the loss fits
πA / (πA + πB)0.9 at P and QSampling A when A or B is sampled
πA0.81 at P; 0.27 at QSampling A at all. Q’s is below qA = ⅓ although its A/B odds rose.

This control chooses which fitted policy to look at. It is not training time and not a path any optimizer follows. Every c between 0 and 1 gives the same loss; the 0.05–0.95 range is a display choice, not an inferred bound. P is c = 0.10 and Q is c = 0.70.

Candidate π(c = 0.30)selected for inspection
  • A0.630000
  • B0.070000 below q
  • C0.300000 below q

Sum 1. One scale from 0 to 1 for all three responses; the tick marks the reference q = ⅓.

Mean record loss 0.562335, πA / πB = 9: the same as P and Q.

Fit is not the optimizer’s choice. Repeating the worked step keeps zA + zB = 0 and zC = 0, so every iterate has πAπB = πC². Its stationary point is (9/13, 1/13, 3/13) ≈ (0.692, 0.077, 0.231), the member c = 3/13. P (0.0729 against 0.01) and Q (0.0081 against 0.49) are off that curve, so neither is a checkpoint of that run. Which fitted policy an optimizer returns depends on its start and update rule; that selection is not further evidence about preferences.

An evaluation written separately

Evaluation rubric

A rubric is a stipulated score for each response, written for this page. It is not a reward inferred from the records and not a measurement of anyone’s values. Choosing one changes no record, logit, loss or gradient.

Expected score Σ πi ui, term by term
PolicyπAuAπBuBπCuCExpected scoreRecord loss
P0.81000.810.562335
Q0.27000.270.562335
π(c = 0.30)0.63000.630.562335

Under uold = (1, 0, 0), P scores higher: 0.81 against 0.27. The two rubrics reverse the ranking of two policies that fit the records equally well.

Unchanged by this choice: the 4 records, the record loss 0.562335 of every row above, and the worked step z₁ = (0.125, −0.125, 0).

What is missing, and what would constrain it

An evaluation judgment
How good is C for this prompt? A value or a bound for t is asked of an evaluator. A value other than t = 0.18, or a bound that excludes it, settles which policy the rubric ranks higher. It adds no training record and changes no fit.
A training comparison involving C
For example B against C, recorded in both directions. Added to the ledger it changes the objective and can fix πC; see the six-record case below. More copies of the four records cannot, because they never mention C.

Equal fit is not complete alignment, and an unjudged response to the same prompt is not a held-out prompt: nothing here is evidence about generalization.

Optional depth

Derivation: loss, gradient, step and the line the steps stay on

With π = softmax(z), log πy = zy − log Σk ezk, so ∇z log πy = ey − π and ∇z(log πw − log πℓ) = ew − eℓ. The reference q is fixed, so ∇zv = β(ew − eℓ).

For one record, ℓ(v) = −log σ(v) = log(1 + e−v), so dℓ/dv = −σ(−v) and ∇zℓ = −β σ(−v)(ew − eℓ). A well-ordered record (large v) pulls weakly; a badly ordered one pulls with weight near 1.

With nAB = 3 and nBA = 1, the mean is L = −(3 log s + log(1 − s)) / 4 with s = σ(β(zA − zB − log(qA/qB))). This is an average of hard labels, not label smoothing. It is minimized at s = 3/4, which gives zA − zB = log(qA/qB) + logit(3/4)/β = 2 log 3, so πA/πB = 9, with minimum H(3/4) = 0.562335 nats. zC does not appear.

Every gradient has the form (g, −g, 0). From z₀ = 0, plain steps therefore keep z = (a, −a, 0), with a ← a + ½η(¾ − σ(a)) at β = ½. The fixed point is a = log 3, giving (9/13, 1/13, 3/13). A finite number of steps approaches it; this holds for this start and plain full-batch steps, not for other initializations, momentum, weight decay or shared parameters.

The ledger’s coverage: the compared responses split into {A, B} and {C}, so no unique policy is identified.

A separate, hypothetical six-record ledger: add B ≻ C and C ≻ B

Records r5 (B ≻ C) and r6 (C ≻ B) are appended under the same comparison task. They are two judgments, not a tie label and not proof of indifference. The comparisons now link A, B and C, and the minimizer is unique up to a common logit shift: π = (9/11, 1/11, 1/11) ≈ (0.818182, 0.090909, 0.090909), with mean record loss 0.605939.

Six-record optimumhypothetical ledger
  • A0.818182
  • B0.090909 below q
  • C0.090909 below q

Sum 1. One scale from 0 to 1 for all three responses; the tick marks the reference q = ⅓.

In this changed ledger the four-record family no longer fits equally: P gives 0.606055 and Q gives 0.700098. The mean 0.605939 belongs to a different dataset than 0.562335; comparing the two is not a measure of improvement.

Copies, a selective record and a one-sided comparison

Whole-ledger copies. The whole ledger written three times, with distinct IDs, makes 12 rows in the same proportions. At z₁ the mean loss is 0.663849 (the four-record value is 0.663849) and the mean gradient is unchanged; only the summed loss triples. Copies are not independent evidence, and they still say nothing about C.

One more A ≻ B record. The counts become 4:1, the share 0.8, and the optimal A/B odds (4)1/β = 16 instead of 9. Duplicating an existing favorable row would reweight the objective in the same way without adding a new judgment.

B ≻ C only. Adding just r5 connects all three responses, but the B–C comparison is one-sided: pushing πC toward 0 keeps lowering the loss (0.593835 at c = 0.1, 0.505064 at c = 0.01, 0.456095 at c = 0.0001) toward (4/5)H(3/4) = 0.449868, which no strictly positive policy attains. Connectedness alone does not give a finite fit. Three A ≻ B records and no reverse record likewise have no finite optimum for the A–B log-ratio.

Full KL to the reference, a diagnostic

KL(P ‖ q) = 0.480955 and KL(Q ‖ q) = 0.390223 nats over all three responses. In the source, β is the coefficient of this KL in the regularized objective from which the loss is derived, but the recorded loss itself has no KL term. A smaller KL is not a tie-break the records supply, and it does not make either policy the intended one.

Source: how this maps onto DPO (Rafailov et al., arXiv 2305.18290v3)
Source operations and this investigation
In the sourceHere
Eq. 7 (§4, printed p. 4): −log σ of β times the winner-minus-loser policy/reference log-ratio differenceEach record’s loss −log σ(v), v = βm
§4 gradient (printed p. 5): weight σ(r̂ℓ − r̂w) on ∇log πw − ∇log πℓ−β σ(−v)(ew − eℓ) for free categorical logits
Appendix B dpo_loss (printed p. 20): per-pair losses and detached rewardspi_logps = log_softmax(z) over (A, B, C), ref_logps = log q, yw_idxs = (0, 0, 0, 1), yl_idxs = (1, 1, 1, 0)
Not in the source’s functionThe mean over rows and one step on free logits are additions made here. No reward model, RL loop or neural network is involved.
§6.4, Appendix C.2 and §7The paper’s own evaluations and discussion. They do not report this constructed utility reversal and are not evidence of generalization here.

A discrepancy in this version. Appendix A.4 (printed p. 17) writes the loss as Eq. 21 with the loser-minus-winner margin inside −log σ, and its final gradient weights each pair by σ(v) rather than σ(−v). Eq. 7, the §4 gradient and Appendix B all use the winner-minus-loser margin, and differentiating Eq. 7 gives the weight σ(−v). This page follows Eq. 7; the note concerns this PDF version, not the method or other versions.

The weights agree only at v = 0, so the worked step at z₀ cannot tell them apart. At P, where each A ≻ B record has v = log 3, the correct weight is σ(−log 3) = ¼, not ¾. The correct mean gradient at P is (0, 0, 0); the printed weight would give (−0.25, 0.25, 0), as though P were not yet fitted.

A different freedom. The source identifies rewards only up to a prompt-only term β log Z(x). Moving from P to Q changes the detached scores β log(π/q) by (−0.549306, −0.549306, 0.972955): not one constant for all responses. The freedom here comes from comparisons that were never recorded.

Source: Rafailov et al. (2023). Direct Preference Optimization: Your Language Model is Secretly a Reward Model. NeurIPS 2023. arXiv:2305.18290v3 (PDF).

The same calculation in Python, run independently

A separate implementation of the ledger, update, policy logits, log-softmax and implicit scores. The site’s test suite runs this exact text with Python and NumPy and compares shared valid and invalid cases with the TypeScript helper. The rubric, interval, sampling-share, identification and display helpers exist only in TypeScript.

import math
import re
from fractions import Fraction

import numpy as np

# One prompt; three complete responses, always in the order A, B, C.
RESPONSES = ("A", "B", "C")
ID_PATTERN = re.compile(r"[A-Za-z0-9][A-Za-z0-9._:-]{0,63}", re.ASCII)
MAX_RECORDS = 10_000
SUM_TOLERANCE = 1e-12


class PreferenceCoverageError(ValueError):
    """A coded refusal: the calculation does not apply, or a value is not representable."""

    def __init__(self, code, detail):
        super().__init__(f"{code}: {detail}")
        self.code = code


def real(x):
    """A Python int or float as binary64, else None. A bool is not a number here."""
    if isinstance(x, bool) or not isinstance(x, (int, float)):
        return None
    try:
        return float(x)
    except OverflowError:
        return None


def vector(value, what):
    if not isinstance(value, (list, tuple)) or len(value) != 3:
        raise PreferenceCoverageError("malformed-vector", f"{what} must be exactly three numbers")
    xs = [real(x) for x in value]
    if None in xs:
        raise PreferenceCoverageError("malformed-vector", f"{what} has a missing or non-numeric entry")
    return xs


def check_logits(z):
    z = vector(z, "logits")
    if not all(map(math.isfinite, z)):
        raise PreferenceCoverageError("nonfinite-logit", "every logit must be finite")
    return z


def check_distribution(p, role):
    """Three finite, strictly positive entries summing to 1: never clamped or renormalized."""
    p = vector(p, role)
    if not all(map(math.isfinite, p)):
        raise PreferenceCoverageError(f"{role}-nonfinite", f"every {role} entry must be finite")
    if any(x < 0 for x in p):
        raise PreferenceCoverageError(f"{role}-negative", f"a {role} entry is negative")
    if any(x == 0 for x in p):
        raise PreferenceCoverageError(f"{role}-zero", "a structural zero: its log-ratio is undefined, so the calculation does not apply")
    if not abs(p[0] + p[1] + p[2] - 1) <= SUM_TOLERANCE:
        raise PreferenceCoverageError(f"{role}-not-normalized", f"{role} entries must sum to 1 within {SUM_TOLERANCE}")
    return p


def check_beta(beta):
    b = real(beta)
    if b is None or not math.isfinite(b) or not b > 0:
        raise PreferenceCoverageError("invalid-beta", "beta must be finite and greater than 0")
    return b


def check_step_size(eta):
    e = real(eta)
    if e is None or not math.isfinite(e) or not e >= 0:
        raise PreferenceCoverageError("invalid-step-size", "the step size must be finite and at least 0")
    return e


def check_records(records):
    """Each record is (id, winner, loser). An empty ledger has no mean and no update."""
    if not isinstance(records, (list, tuple)):
        raise PreferenceCoverageError("malformed-ledger", "records must be a list")
    if not records:
        raise PreferenceCoverageError("empty-ledger", "no records: no empirical mean and no update, not a loss of 0")
    if len(records) > MAX_RECORDS:
        raise PreferenceCoverageError("too-many-records", f"at most {MAX_RECORDS} records")
    seen = set()
    for i, record in enumerate(records):
        if not isinstance(record, (list, tuple)) or len(record) != 3:
            raise PreferenceCoverageError("malformed-record", f"record {i} must be (id, winner, loser)")
        rid, w, l = record
        if not isinstance(rid, str) or not ID_PATTERN.fullmatch(rid):
            raise PreferenceCoverageError("invalid-id", f"record {i} needs an ID such as r1")
        if not all(isinstance(x, str) and x in RESPONSES for x in (w, l)):
            raise PreferenceCoverageError("invalid-label", f"record {rid}: winner and loser must be A, B or C")
        if w == l:
            raise PreferenceCoverageError("same-response", f"record {rid} compares {w} with itself")
        if rid in seen:
            raise PreferenceCoverageError("duplicate-id", f"record ID {rid} appears twice")
        seen.add(rid)
    return [tuple(r) for r in records]


def softplus(x):
    """log(1 + e^x) without overflow. A record's loss is softplus(-v) = -log sigmoid(v)."""
    return x + math.log1p(math.exp(-x)) if x > 0 else math.log1p(math.exp(x))


def sigmoid(x):
    if x >= 0:
        return 1 / (1 + math.exp(-x))
    e = math.exp(x)
    return e / (1 + e)


def mean(values):
    """Divide each term first, add left to right (not sum(), which compensates); refuse a mean that rounds past the largest double."""
    n, total = len(values), 0.0
    for v in values:
        total += v / n
    return finite(total, "the mean")


def finite(x, what):
    if not math.isfinite(x):
        raise PreferenceCoverageError("unrepresentable", f"{what} is not representable in binary64")
    return x


def evaluate(z, q, records, beta):
    """Every record at the same logits z, then the mean loss and the mean gradient."""
    beta, z = check_beta(beta), check_logits(z)
    q, records = check_distribution(q, "reference"), check_records(records)
    log_q = [math.log(x) for x in q]
    rows = []
    for rid, w, l in records:
        i, j = RESPONSES.index(w), RESPONSES.index(l)
        policy = finite(z[i] - z[j], "z_w - z_l")  # = log pi_w - log pi_l: the normalizer cancels
        reference = log_q[i] - log_q[j]  # kept explicit even when it is 0
        m = finite(policy - reference, "the margin m")
        v = finite(beta * m, "beta * m")
        grad = [0.0, 0.0, 0.0]
        grad[i], grad[j] = -beta * sigmoid(-v), beta * sigmoid(-v)  # -beta sigma(-v) (e_w - e_l)
        rows.append({"id": rid, "m": m, "v": v, "s": sigmoid(v), "loss": softplus(-v), "grad": grad})
    return {
        "rows": rows,
        "loss": mean([r["loss"] for r in rows]),
        "grad": [mean([r["grad"][c] for r in rows]) for c in range(3)],
    }


def step(z, q, records, beta, eta):
    """One full-batch update: all rows at the same z, averaged, then z' = z - eta * mean gradient."""
    beta, eta, z = check_beta(beta), check_step_size(eta), check_logits(z)
    before = evaluate(z, q, records, beta)
    z_next = [finite(z[c] - eta * before["grad"][c], "a stepped logit") for c in range(3)]
    return z_next, before, evaluate(z_next, q, records, beta)


def softmax(z):
    top = max(z)
    e = [math.exp(x - top) for x in z]
    return [x / (e[0] + e[1] + e[2]) for x in e]


def policy_logits(p):
    """z = log pi for a supplied positive policy (any common shift would do)."""
    return [math.log(x) for x in check_distribution(p, "policy")]


# Appendix B of the source (arXiv 2305.18290v3), with NumPy in place of PyTorch.
# -F.logsigmoid(x) is softplus(-x), which np.logaddexp(0, -x) computes stably.
def dpo_loss(pi_logps, ref_logps, yw_idxs, yl_idxs, beta):
    pi_yw_logps, pi_yl_logps = pi_logps[yw_idxs], pi_logps[yl_idxs]
    ref_yw_logps, ref_yl_logps = ref_logps[yw_idxs], ref_logps[yl_idxs]
    pi_logratios = pi_yw_logps - pi_yl_logps
    ref_logratios = ref_yw_logps - ref_yl_logps
    losses = np.logaddexp(0.0, -beta * (pi_logratios - ref_logratios))
    rewards = beta * (pi_logps - ref_logps)  # .detach() in the source: scores, not a training signal
    return losses, rewards


def log_softmax(z):
    """In shifted coordinates, so a common offset cannot absorb the normalizer; an unrepresentable shift is refused."""
    z = check_logits(z)
    top = max(z)
    shifted = [finite(x - top, "a shifted logit") for x in z]
    return np.array(shifted) - math.log(math.exp(shifted[0]) + math.exp(shifted[1]) + math.exp(shifted[2]))


def implicit_scores(p, q, beta):
    """beta log(pi / q) per response, the source's detached score; a product out of range is refused."""
    beta, p, q = check_beta(beta), check_distribution(p, "policy"), check_distribution(q, "reference")
    return [finite(beta * (math.log(a) - math.log(b)), "a scaled score") for a, b in zip(p, q)]


q = [1 / 3, 1 / 3, 1 / 3]
records = [("r1", "A", "B"), ("r2", "A", "B"), ("r3", "A", "B"), ("r4", "B", "A")]
beta, eta, z0 = 0.5, 1.0, [0.0, 0.0, 0.0]

# 1. One full-batch step from z0.
z1, before, after = step(z0, q, records, beta, eta)
print("row gradients at z0:", [r["grad"] for r in before["rows"]])
print("mean gradient:", before["grad"], "-> z1:", z1)
print("pi(z1):", [round(x, 12) for x in softmax(z1)])
print("mean loss:", round(before["loss"], 12), "->", round(after["loss"], 12))
print("row losses at z1:", [round(r["loss"], 6) for r in after["rows"]])
assert [r["grad"] for r in before["rows"]] == 3 * [[-0.25, 0.25, 0.0]] + [[0.25, -0.25, 0.0]]
assert before["grad"] == [-0.125, 0.125, 0.0] and z1 == [0.125, -0.125, 0.0]
# The same four rows written as counts: -(3 log s + log(1 - s)) / 4, with s = sigma(beta (z_A - z_B)).
s1 = sigmoid(beta * (z1[0] - z1[1]))
assert math.isclose(after["loss"], -(3 * math.log(s1) + math.log(1 - s1)) / 4, rel_tol=1e-14)
# The after-state again from literal logits, not from the step's own output. The mean fell; r4's loss rose.
again = evaluate([0.125, -0.125, 0.0], q, records, beta)
assert again["loss"] == after["loss"] < before["loss"] < after["rows"][3]["loss"]
# C's logit gradient is 0, yet pi_C moved: the softmax denominator changed.
assert before["grad"][2] == 0 and softmax(z1)[2] < 1 / 3
# The source's operation returns the same row losses at z0 and at z1.
chosen, rejected = np.array([0, 0, 0, 1]), np.array([1, 1, 1, 0])
for z, state in ((z0, before), (z1, after)):
    losses, _ = dpo_loss(log_softmax(z), np.log(q), chosen, rejected, beta)
    assert np.allclose(losses, [r["loss"] for r in state["rows"]], rtol=1e-13, atol=0)

# 2. Repeating this step keeps z_A + z_B = 0 and z_C = 0, so pi_A pi_B = pi_C ** 2 along the whole path.
z = z0
for _ in range(400):
    z, _, _ = step(z, q, records, beta, eta)
    assert z[0] + z[1] == 0 and z[2] == 0
print("400 steps approximate the stationary point (9/13, 1/13, 3/13):", [round(x, 9) for x in softmax(z)])
assert max(abs(a - b) for a, b in zip(softmax(z), [9 / 13, 1 / 13, 3 / 13])) < 1e-9

# 3. A different question: supplied policies that fit the four records equally well.
P, Q = [0.81, 0.09, 0.10], [0.27, 0.03, 0.70]
H = -(0.75 * math.log(0.75) + 0.25 * math.log(0.25))  # the minimum mean loss when 3 of 4 prefer A
for name, p in (("P", P), ("Q", Q)):
    fit = evaluate(policy_logits(p), q, records, beta)
    assert math.isclose(fit["loss"], H, rel_tol=1e-12) and max(map(abs, fit["grad"])) < 1e-12
    print(f"{name}: loss {fit['loss']:.12f}; predicted A over B {fit['rows'][0]['s']:.6f};",
          f"sampling A given A or B {p[0] / (p[0] + p[1]):.6f}; sampling A {p[0]:.2f};",
          f"pi_A pi_B - pi_C^2 = {p[0] * p[1] - p[2] ** 2:.4f}")


def kl(p):
    return sum(x * (math.log(x) - math.log(r)) for x, r in zip(p, q))


print(f"KL(P || q) = {kl(P):.12f}, KL(Q || q) = {kl(Q):.12f}; a diagnostic, the loss has no KL term")
# The source's detached scores change by different amounts per response from P to Q: not one prompt-only constant.
shift = np.subtract(implicit_scores(Q, q, beta), implicit_scores(P, q, beta))
assert np.allclose(shift, [-0.5 * math.log(3), -0.5 * math.log(3), 0.5 * math.log(7)])
_, rewards_P = dpo_loss(log_softmax(policy_logits(P)), np.log(q), chosen, rejected, beta)
assert np.allclose(rewards_P, implicit_scores(P, q, beta))  # the transcription's rewards are these scores


# 4. The pinned appendix's final line weights each record by sigma(v); Eq. 7 differentiates to sigma(-v).
def printed_weight_gradient(z, q, records, beta):
    rows, grads = evaluate(z, q, records, beta)["rows"], []
    for (_, w, l), row in zip(records, rows):
        g = [0.0, 0.0, 0.0]
        i, j = RESPONSES.index(w), RESPONSES.index(l)
        g[i], g[j] = -beta * row["s"], beta * row["s"]
        grads.append(g)
    return [mean([g[c] for g in grads]) for c in range(3)]


zP = policy_logits(P)
correct, printed = evaluate(zP, q, records, beta)["grad"], printed_weight_gradient(zP, q, records, beta)
print("gradient at P (v = log 3):", [round(x, 12) for x in correct], "; with the printed weight:", [round(x, 12) for x in printed])
assert max(map(abs, correct)) < 1e-12 and math.isclose(printed[0], -0.25, rel_tol=1e-12)
assert printed_weight_gradient(z0, q, records, beta) == before["grad"]  # equal at v = 0: a zero-margin test cannot tell

# 5. The analytic gradient against central differences, at nonzero margins and a nonuniform reference.
six = records + [("r5", "B", "C"), ("r6", "C", "B")]
q2, z2, h = [0.5, 0.25, 0.25], [0.3, -0.7, 1.1], 1e-6
g2 = evaluate(z2, q2, six, 0.8)["grad"]
for c in range(3):
    up, down = list(z2), list(z2)
    up[c], down[c] = z2[c] + h, z2[c] - h
    fd = (evaluate(up, q2, six, 0.8)["loss"] - evaluate(down, q2, six, 0.8)["loss"]) / (2 * h)
    assert abs(fd - g2[c]) < 1e-8

# 6. Evaluation: rubrics written for this page, in exact arithmetic. They change no record, logit, loss or gradient.
Pf = [Fraction(x) for x in ("0.81", "0.09", "0.10")]
Qf = [Fraction(x) for x in ("0.27", "0.03", "0.70")]


def utility(p, u):
    return sum(x * y for x, y in zip(p, u))


u_old, u_new = [1, 0, 0], [Fraction("0.2"), 0, 1]
print("u_old:", utility(Pf, u_old), utility(Qf, u_old), "| u_new:", utility(Pf, u_new), utility(Qf, u_new))
# C unscored: u = (0.2, 0, t) with t in [0, 1], so U(t) = 0.2 pi_A + pi_C t stays symbolic.
gap, slope = Pf[0] * Fraction("0.2") - Qf[0] * Fraction("0.2"), Pf[2] - Qf[2]
print(f"U_P(t) - U_Q(t) = {gap} + ({slope}) t; equal at t = {-gap / slope}")
assert -gap / slope == Fraction(9, 50) and gap > 0 > gap + slope  # P above Q at t = 0, below at t = 1

# 7. Optional data depth: a unique optimum, a connected graph without one, and copies.
fit6 = evaluate(policy_logits([9 / 11, 1 / 11, 1 / 11]), q, six, beta)
assert math.isclose(fit6["loss"], (4 * H + 2 * math.log(2)) / 6, rel_tol=1e-12) and max(map(abs, fit6["grad"])) < 1e-12
print(f"six records: optimum (9/11, 1/11, 1/11), mean loss {fit6['loss']:.12f}")
one_sided = records + [("r5", "B", "C")]
path = [evaluate(policy_logits([0.9 * (1 - c), 0.1 * (1 - c), c]), q, one_sided, beta)["loss"] for c in (0.1, 0.01, 0.0001)]
print("B over C only, as c -> 0:", [round(x, 12) for x in path], "> infimum 4H/5 =", round(4 * H / 5, 12))
assert path[0] > path[1] > path[2] > 4 * H / 5
copies = [(rid if k == 1 else f"{rid}-copy{k}", w, l) for k in (1, 2, 3) for rid, w, l in records]
assert math.isclose(evaluate(z1, q, copies, beta)["loss"], after["loss"], rel_tol=1e-14)  # same mean, not new evidence
selective = records + [("r5", "A", "B")]  # counts 4:1, so the optimal A/B odds are 16, not 9
assert max(map(abs, evaluate(policy_logits([0.8 * 16 / 17, 0.8 / 17, 0.2]), q, selective, beta)["grad"])) < 1e-12


# 8. Where the calculation does not apply, or a value is not representable: a coded refusal, no repair.
def refusal(f, *args):
    try:
        f(*args)
    except PreferenceCoverageError as error:
        return error.code
    return None


assert refusal(evaluate, z0, [0.5, 0.5, 0.0], records, beta) == "reference-zero"
assert refusal(evaluate, z0, [0.5, 0.25, 0.26], records, beta) == "reference-not-normalized"
assert refusal(evaluate, z0, q, [], beta) == "empty-ledger"
assert refusal(evaluate, z0, q, [("r1", "A", "A")], beta) == "same-response"
assert refusal(evaluate, z0, q, [("r1", "A", "Z")], beta) == "invalid-label"
assert refusal(evaluate, [1e308, -1e308, 0.0], q, records, beta) == "unrepresentable"
assert refusal(log_softmax, [1.7e308, -1.7e308, 0.0]) == "unrepresentable"
assert refusal(implicit_scores, [0.8, 0.1, 0.1], [0.01, 0.49, 0.5], 1e308) == "unrepresentable"
# A common offset keeps the normalizer: each log-probability is -log 3, not 0.
assert np.allclose(log_softmax([1e20, 1e20, 1e20]), [-math.log(3)] * 3, rtol=1e-15, atol=0)
extreme = evaluate([1000.0, -1000.0, 0.0], q, records, beta)  # pi_B and pi_C underflow to 0; the loss does not
assert extreme["loss"] == 250.0 and extreme["grad"] == [0.125, -0.125, 0.0] and softmax([1000.0, -1000.0, 0.0])[1:] == [0.0, 0.0]
print("refusals checked; at logits (1000, -1000, 0) the mean loss is", extreme["loss"])
Where the calculation does not apply, or is not representable

The helper refuses rather than repairs: no epsilon, clamping, renormalizing or dropped record. Each line is its actual response.

  • reference q = (0.5, 0.5, 0) with the four recordsreference-zero: a reference entry is exactly 0, so a log-ratio involving it is undefined; the calculation does not apply (no epsilon is added)
  • reference q = (0.5, 0.25, 0.26)reference-not-normalized: reference entries sum to 1.01, not 1 within 1e-12; nothing is renormalized
  • no recordsempty-ledger: no records: there is no empirical mean and no update (not a loss of 0)
  • record r1: A ≻ Asame-response: record r1 compares A with itself
  • two records both named r1duplicate-id: record ID r1 appears twice
  • β = 0invalid-beta: beta must be a finite number greater than 0
  • logits (10³⁰⁸, −10³⁰⁸, 0)unrepresentable: z_A - z_B is not representable in binary64; nothing is returned or applied

Finite extremes are different: at logits (1000, −1000, 0) the displayed probabilities round to (1, 0, 0), yet the mean record loss is 250 and the mean gradient (0.125, −0.125, 0), computed from logit differences rather than from logs of rounded probabilities.

Optional practice, with answers on request

Rehearsal with the worked values above in view. Opening an answer is help; a later retry is practice, not a test. Nothing is recorded.

  1. At z₀, which way does r4’s own gradient push zA, and why does the step still raise it?

    Show an answer

    r4’s gradient is (0.25, −0.25, 0); subtracting it lowers zA for that record alone. The step uses the mean: (3 · (−0.25) + 0.25) / 4 = −0.125 for A, so zA rises by 0.125.

  2. zC is still 0 after the step. Why did πC change?

    Show an answer

    πC = 1 / (e0.125 + e−0.125 + 1): the normalizer grew from 3 to 3.015645.

  3. P and Q have the same record loss. Which should be used?

    Show an answer

    The records cannot say. They fix πA/πB only. The answer depends on an evaluation rubric; with C’s score known only to lie in [0, 1], it depends on t. What is missing is a judgment about C, or comparisons that involve C.

  4. Two extra copies of the whole ledger, or one extra A ≻ B record: which changes the optimum?

    Show an answer

    The extra record: counts 4:1 give odds 16. Whole-ledger copies keep the mean and the optimum. Neither is new independent evidence about C.

In focus

Concept: Direct Preference Optimization

What is the smallest example of Direct Preference Optimization you can work through by hand, and what does it show?

BeforeCross-EntropyNextKahneman-Tversky Optimization
DetailsAlignment

After the first pass

Go deeper

Optional material for a second reading. Sources are always shown; the other panels open from their headings or from these links, and closing one keeps what you wrote or revealed.
What to look for in each sectionChoose a section and what you expect to see in it, then read short advice.

Section by section

Choose what to look for in each section

DPO turns pairwise preferences into binary cross-entropy on reference-relative log odds, using the KL-regularized RLHF optimum to make the policy itself an implicit reward model.

Choose what to look for (no demo yet)01 / Intuition
Illustration of a direct preference comparison tilting chosen and rejected probability paths.
What to look for

Start with the picture, metaphor, or geometric mechanism.

Choose first

Choose what you expect to see in this section of Direct Preference Optimization.

Questions to ask of the pictureChoose a part of the picture and what you expect, then read short advice.

Looking at the picture

Questions to ask of the picture

DPO turns pairwise preferences into binary cross-entropy on reference-relative log odds, using the KL-regularized RLHF optimum to make the policy itself an implicit reward model.

4 of 4 sections writtenNo live demo yet
Question

Which part of the picture should you look at first?

Choose first

Pick the part of the picture you expect to explain Direct Preference Optimization.

Sources

References for this page

A reference shows where an idea comes from; it does not vouch for every step on this page.
paper · 2023Direct Preference Optimization: Your Language Model is Secretly a Reward ModelRafailov et al.
Why it is cited

NeurIPS 2023. Derives DPO from the KL-regularized RLHF objective: the optimal policy defines an implicit reward, and the Bradley-Terry likelihood of that reward becomes a binary cross-entropy loss on the policy itself.

Open source
paper · 2024A General Theoretical Paradigm to Understand Learning from Human PreferencesAzar et al.
Why it is cited

AISTATS 2024. Shows that when preferences are deterministic, the DPO optimum sets the loser's probability to zero whatever the KL coefficient, and proposes IPO, whose target stays finite.

Open source
paper · 2024Is DPO Superior to PPO for LLM Alignment? A Comprehensive StudyXu et al.
Why it is cited

ICML 2024. Argues that DPO can favor responses outside the preference data, and reports that a well-tuned PPO outperformed DPO on the dialogue and code-generation benchmarks studied.

Open source
paper · 1952Rank Analysis of Incomplete Block Designs: I. The Method of Paired ComparisonsBradley and Terry
Why it is cited

Biometrika 39(3/4). The paired-comparison model DPO assumes: P(i beats j) = sigma(r_i - r_j) when each item's strength is exp(r).

Open source
book · 2026Reinforcement Learning from Human FeedbackLambert
Why it is cited

Manning, 2026; the same text is free on arXiv and at rlhfbook.com. Its chapter on direct alignment methods treats DPO alongside reward-model and PPO pipelines.

Open source
What each claim rests on1 claim, each with its sources, where it appears on this page, and its caveats.

Claims and sources

DPO turns pairwise preferences into binary cross-entropy on reference-relative log odds, using the KL-regularized RLHF optimum to make the policy itself an implicit reward model.

Checked against the cited passages

The checks were made by this site, not by an independent reviewer.

DPO reparameterizes the KL-regularized RLHF reward as beta times the policy/reference log-ratio, up to a prompt-only constant, then fits preference pairs with binary cross-entropy on the beta-scaled winner-loser reference-relative log-odds margin.
What the sources support

Rafailov et al. solve the KL-regularized objective, write the reward as beta log(pi_r/pi_ref) plus a prompt-only term and put it into the Bradley-Terry model, where that term cancels to leave the DPO loss.

Where to see it on this page
Equation 1
r^θ(x,y)=βlog⁡πθ(y∣x)πref(y∣x).\hat r_\theta(x,y) = \beta\log\frac{\pi_\theta(y\mid x)}{\pi_{\mathrm{ref}}(y\mid x)}.
Caveat

Covers the pairwise derivation and small exact examples. Not covered: finite-sample behavior, noisy hard labels, neural parameterizations, ranking variants, or whether DPO beats PPO in practice; it does not...

StatusChecked against the cited passages.

Rafailov et al. derive the optimum pi_r proportional to pi_ref exp(r/beta), rearrange it as r = beta log(pi_r/pi_ref) + beta log Z(x), and cancel Z(x) in the Bradley-Terry reward difference. The result is a logistic (binary cross-entropy) loss on beta times the winner-minus-loser log-odds of the policy relative to the reference.

Explain it without the pageWrite your own explanation before asking for feedback. Your draft and any hints stay while this page is open.

Practice · Direct Preference Optimization

Try the idea in your own words

DPO turns pairwise preferences into binary cross-entropy on reference-relative log odds, using the KL-regularized RLHF optimum to make the policy itself an implicit reward model.

Concept · Selected for practice

Direct Preference Optimization

What it rests on: Sources: Direct Preference Optimization: Your Language Model is Secretly a Reward Model; A General Theoretical Paradigm to Understand Learning from...

Context and links
Choose a task

Explain the mechanism

For Direct Preference Optimization: What is the smallest example of Direct Preference Optimization you can work through by hand, and what does it show? Explain your answer, including what changes, why, and which assumption matters.

No answer yet

A rough first thought is enough. Your draft stays when you change tasks.

Your draft stays on this page and is cleared when you leave or reload.

A little help · Explain

Open one hint at a time. These are suggestions, not your answer or a grade.

0 of 3 hints shown for this question.

    Clearing your answer keeps this help record. Outside help is your own report; this page cannot check it.

    Where am I stuck? (optional)
    Your own description, not an automatic diagnosis

    Choose one, or leave this unspecified. Select it again to clear it.

    Take your draft to a feedback conversation

    No AI feedback runs here. You can copy a prompt to use elsewhere; nothing is sent automatically. Review the text before sharing, and leave out private information.

    Write an attempt before copying a feedback prompt.

    A draft, or an AI reply to it, is not a test of what you have learned. To check that, try a different case later without help.

    Ask about this pagePick one item on this page and copy a prompt about it into an AI assistant you already use. Notes you write here stay in this browser.
    Ask about this pageClose
    ConceptDirect Preference OptimizationSources: Direct Preference Optimization: Your Language Model is Secretly a Reward Model; A General Theoretical Paradigm to Understand Learning from...assert np.allclose(pi, pi_star, atol=1e-6)

    Your question

    Choose what your question is about

    Pick the idea, equation, source, code, claim, misconception or demo state you want to ask about. The prompt you copy includes it, so the answer can stay on that item.
    Next local actionNo local draft saved yet

    Open the draft below to save one note and next action in this browser.

    conceptAlignment

    Direct Preference Optimization

    Starting question

    What is the smallest example of Direct Preference Optimization you can work through by hand, and what does it show?

    SourcesCheck the 5 cited sources listed under Sources.Notes can be saved for this item
    Points of view on this item

    Fixed prompts generated from this item. They are not comments from people or independent reviews.

    Learner’s first stepAsk what would make "Direct Preference Optimization" feel predictable rather than familiar.
    Assumption

    The 5 cited sources must support this exact item, not just the surrounding topic.

    Source-checking summary

    Connect the definition to one equation, piece of code or demo before widening the discussion.

    Proposed experiment

    Change one input, then check that the same relationship holds in the mathematics, the code and the demo.

    Next action

    You can state the mechanism in your own words

    Evidence4 checks
    ObservationChecking for a saved observation
    ActionReady for one action
    PromptLearner prompt ready to copy
    Go to this item
    01ObservationChecking what this browser has saved
    02EvidenceChecking for a saved observation
    03SourcesCheck the 5 cited sources listed under Sources.
    04Next stepSave one next action
    Local action draftNo local draft saved yetOpen when you are ready to write one next action
    Local action draft

    This draft stays in this browser and is attached to this item only.

    No local draft saved.
    Evidence to inspect
    • What the 5 cited sources say about this exact item
    • The definition, its prerequisites, and a contrasting concept
    • The equation or code that makes the concept concrete
    • One demo state that shows what stays the same as the inputs change
    What would resolve this
    • You can state the mechanism in your own words
    • You can name the prerequisite that would clear up the confusion
    • You can predict how the result changes when one input changes
    Reference idconcept/concept-notebook/alignment/dpo concept:alignment/dpo
